ModelMPE-6501-ACABW-3B
ATX VersionATX 12V Ver. 3.1
PFCActive PFC
Input Voltage200-240V
Input Current5A
Input Frequency50-60Hz
Dimensions (L x W x H)140 x 150 x 86 mm / 5.5 x 5.9 x 3.4 inch
Fan Size120mm
Fan BearingHDB
Efficiency>88% @ Typical Load
80 PLUS Rating80 PLUS Bronze EU 230V
ErP 2014 Lot 3Yes
Operating Temperature0-40°C
Power Good Signal100 - 150 ms
Hold Up Time>16ms
MTBF>100,000 Hours
ProtectionsUVP / OVP / OPP / OTP / SCP
RegulatoryTUV, CE, FCC, CCC, EAC, RCM, UKCA, RoHS2.0 / BIS, KC (based on region's request.)
ATX 24 Pin Connectors1
EPS 8 Pin / 4+4 Pin Connectors2
SATA Connectors6
Peripheral 4 Pin Connectors3
PCI-e 6+2 Pin Connectors4
Warranty5 Years
SeriesMWE Bronze Series
Category500 to 750W
ModularNon Modular
80 Plus EfficiencyBronze
